This CANON LBP-2460 service manual contains basic information required for the after-sales service of the LBP-2460 laser beam printer hereinafter referred to as the printer. This CANON LBP-2460 service manual includes the following chapters: information is vital for the service technician in maintaining print quality and printer performance. The 2,000-sheet paper deck, option controller, envelope feeder and two-sided printing unit, which are prepared for the optional printer, are also described in this manual. In this manual, the optional 2,000-sheet bridge is simply called the paper bridge. This CANON LBP-2460 service manual includes the following chapters: Chapter 1: Product Information, Characteristics, Specifications, Operation and Installation Chapter 2: Operation and Schedule, a description of the operating principles and timing of sequences of electrical and mechanical systems. Chapter 3: Mechanical System, Explanation of Operating Procedures, Disassembly, Reassembly and Mechanical Adjustment Chapter 4: Troubleshooting, Maintenance, and Maintenance, Reference to Values and Adjustments, Troubleshooting Procedures, Lubricants, and Solvents General timing, general wiring diagram, etc.
The information contained in this CANON LBP-2460 service manual may be modified as the product is enhanced or redesigned. All relevant information in such cases will be provided in the Service Information Bulletins. A thorough understanding of this printer based on the information contained in this manual and the Service Information Bulletins is required to maintain its performance and to locate and repair the causes of malfunctions. The controller of this printer has equipped Intel i960HD processor which allows a print speed of up to 24 pages per minute. (A4 format, or letter size paper). High-resolution printing at 600 x 600 dpi (dots per inch) is further enhanced with AIR (Automatic Refinement Imaging) technology to smooth stair edges and use superfine toner. The optional duplex unit allows the printer to perform automatic two-sided printing. By mounting the optional paper bridge, paper handling capacity is triggered by 2,000 sheets (75g / m2). As a result, uppercase/lowercase cassettes, multi-purpose tray, and paper bridge together can accommodate a total of 3,100 sheets (75 g / m2) for continuous large-volume printing.
Adding optional paper bin and envelope feeder to standard cassette and uppercase/lowercase cassettes result in a 5-way paper capacity feed. Memory reduction technology achieves a 600 x 600 dpi print with only 4 MB of memory. Complex data is compressed. The printer saves electricity by automatically reducing power consumption when it stays idle for a specified amount of time. The printer then returns to full power after you press a button on the control panel or the print job is started. To save the toner the power save mode can be selected to print drafts with less toner. Besides the standard bi-directional parallel interface (Centronics plug), the printer was equipped with extension port which allows the network card to be installed. And, the data sent from the host computer automatically switches between the two interfaces entering any interface port. This printer supports the language of the Hewlett-Packard enhanced PCL5 printer. When the optional Canon A4 Translator Module (ROM Add-In) is installed, the printer also supports Adobe PostScript Level 2. The printer can sample the print data as it is received and then automatically switch between Personalities PCL and PostScript.
 |
